Tripp Lite Easy Pull Long-Run Display Cable EZA-100 User Manual

Model #: eza-100

background image

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail:

[email protected]

Model #: EZA-100

100-ft. Easy Pull Long-Run Display Cable - Type-A Analog PVC Trunk Cable

Highlights

Versatile trunk cable allows for a variety of connection options

At a diameter of 7/8 in., it easily pulls through conduit or confined spaces using

the included end cap with integrated pull tab

High quality RGB style VGA cable supports resolutions up to 1600 x 1200

Description

Tripp Lite's EZA-100 100 ft. Easy Pull VGA Trunk cable makes pulling video cable through conduit or confined areas a breeze. Threaded ends
feature screw on pull-caps, which can be attached to fish tape. Choose from a variety of connector choices that easily screw on to the threaded ends
of the trunk cable. Trunk cables are available in 35 ft., 50 ft. and 100 ft. lengths, PVC and plenum rated. Cable ends are colored-coded green to
denote VGA applications (Digital trunk cables are Yellow). Cable features triple-shielded construction with 75 ohm coax conductors for RGBHV
signals supporting resolutions up to 1600 x 1200.

Applications

Use where standard VGA cables won't fit, such as conduit or confined wall or ceiling spaces

Package Includes

Easy Pull Type-A VGA Analog PVC Trunk Cable, 100 ft.

Features

Eliminates the need to field terminate VGA connectors

Detachable, screw-on connectors

Allows cable to be run according to code - inside conduit, drop ceilings, etc.

At a diameter of 7/8 in., it makes pulling long cables fast and easy

Protects entire cable from strain, dirt, debris and damage

Choose from a variety of connector combinations for the perfect fit

Available in 35 ft., 50 ft. and 100 ft. lengths, both PVC and plenum rated

Specifications

OVERVIEW

Intended Application

Home Theater/AV, Connecting Peripherals

Cable Type

VIDEO

Display Style

Easy Pull

INPUT

Cable Length (ft.)

100
