FCC STATEMENT
The adapter has been tested and found to comply with the limits for
a class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Ø Reorient or relocate the receiving antenna.
Ø Increase the separation between the equipment and receiver.
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a
registered trademark of TP-LINK Technologies Co., Ltd. Other
brands and product names are trademarks or registered trademarks
of their respective holders.
No part of the specifications may be reproduced in any form or by
any means or used to make any derivative such as translation,
transformation, or adaptation without permission from TP-LINK
Technologies Co., Ltd. Copyright © 2005 TP-LINK Technologies Co.,
Ltd. All rights reserved.
Ø Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
EC DECLARATION OF CONFORMITY (EUROPE)
In compliance with the EMC Directive 89/336/EEC, the adapter
meets the requirements of the following standards:
Ø EN55022
Ø EN55024
SAFETY NOTICES
Caution:
Do not use this product near water, for example, in a wet basement
or near a swimming pool.
Avoid using this product during an electrical storm. There may be a
remote risk of electric shock from lightning.
Thank you for purchasing TP-LINK TG-3269 10/100/1000M Gigabit
Ethernet Adapter. This document provides detailed guidelines to
install and use the adapter for network installers or users.
TG-3269 is a 32-bit PCI 10/100/1000Mbps NWay Gigabit LAN
adapter. TG-3269 provides extremely fast data transfer rates up to
2000Mbps at full duplex mode for high bandwidth usage in areas
such as network servers, workstations, Storage Area Networks
(SANs), Network Attach Storage (NAS) and high-speed video
streaming.
This manual is divided into two chapters and two appendices. The
following summarizes the contents of the chapters and appendices.
Chapter 1 Introduction
Hardware Overview
TG-3269 is a highly integrated and cost-effective single-chip Gigabit
Ethernet Adapter that provides 32-bit performance, PCI bus master
capability, and full compliance with IEEE 802.3 10Base-T,
IEEE802.3u 100Base-TX and IEEE 802.3ab 1000Base-T
specifications. It also supports ACPI, PCI power management for
modern operating systems that are capable of Operating System
Directed Power Management (OSPM) to achieve the most efficient
power management.
Through the aid of a VLAN membership, TG-3269 adheres to the
802.1Q for multiple VLAN support, and 802.1P for packet
prioritization. With 802.1Q support, server resources can be shared
with multiple VLANs when used in conjunction with any 802.1Q-
enabled Switch. With the 802.1p support, TG-3269 allows a range of
Ethernet packets to be prioritized from a critical to a non-critical
designation through a priority tag.
TG-3269 supports Full Duplex operations at 20/200/2000 Mbps data
speeds used in conjunction with 802.3x flow control support. With
802.3x flow control TG-3269 uses both asymmetric and symmetric
functions via the MAC control pause function. Any participating
802.3x flow control node can be controlled by initiating a pause
control to stop incoming network traffic, to further reduce network
congestion.
By default TG-3269 supports me size. In
addition, TG-3269 can also be configured to use a maximum Jumbo
Frame size of
It includes an interface for a boot ROM and can be used in diskless
workstations, providing maximum network security and ease of
management.
Also, being PCI 2.2 compliant, TG-3269 works with 32-bit 33Mhz
PCI busses. This compatibility provides users with an easy migration
path to increase performance between servers and workstations for
large file transfer, video editing and server clustering for data
intensive applications.
Features & Advantages
Ø Integrated Ethernet MAC, Physical chip and transceiver in one
chip
Ø Complies with the IEEE802.1P, IEEE802.1Q, IEEE802.3
10Base-T, IEEE802.3u 100Base-TX and IEEE802.3ab
1000Base-T standard
Ø Compliant to PCI Revision 2.1/2.2
the standard 1518 Byte fra
up to 7680Bytes.
