Product Brief: Veta™ iHA Series – Half Brick
©2001 Innoveta Technologies™, Inc.
iHA48060A018V product brief 090302.doc 9/4/2002
' (877) 498-0099
2/2
Product
Identifier
Package
Size
Platform
Input
Voltage
Output
Current/
Power
Output
Units
Main
Output
Voltage
# of
Outputs
Safety
Class
Feature Set
i
H
A
48
060
A
018
V
-
0
00
Innoveta
Technologies™
Half Brick
Veta™
36-75V
040 – 40
060 – 60
Amps
018 – 1.8V
Single
00 – Standard
PIN
FUNCTION
PIN
FUNCTION
1
Vin (+)
7
Trim
2
On/Off
8
Sense (+)
3
Case (Omit Optional)
9
Vout (+)
4
Vin (-)
5
Vout (-)
6
Sense (-)
Feature
Set
On/Off
Logic
Omit
pin3
Output OVP
Pin
Length
00
Positive
No
Latching
0.145”
01
Negative
No
Latching
0.145”
02
Positive
Yes
Auto-Recovery
0.145”
03
Negative
Yes
Auto-Recovery
0.145”
04
Positive
No
Latching
0.110”
05
Negative
No
Latching
0.110”
06
Positive
Yes
Auto-Recovery
0.110”
07
Negative
Yes
Auto-Recovery
0.110”
Top view - Footprint
Ordering Information
