MODEL 12185 TROY-BILT ® 7HP ECONO-HORSE TILLER
3
REF PART
No. No. DESCRIPTION QTY.
REF PART
No. No. DESCRIPTION QTY.
1 1916999 Handlebars
(Incl. Ref No's 2, 3, 3A & 4)....... 1
2 9125 Grip, handlebars ............................ 2
3 1916935 Decal-Operator Control Panel ........ 1
3A 2723 Decal-Troy-Bilt logo ....................... 1
4 9251 Grommet, plastic ........................... 1
5 20703 Handle, height adj.......................... 1
5A 9955 Washer, keyed ............................... 1
6 1900475001 Bracket, handlebar height adjustment . 1
7 1100046 Screw, hex hd., 3/8-16 x 1, GR5.... 2
8 9904 Washer–flat, 3/8, S.A.E.................. 2
9 9837 Locknut, hex hd., 3/8-16 ............... 2
10 9338 Cotter, hairpin ................................ 3
11 20830 Lever, clutch-maneuvering
(Incl. Ref No. 12) ....................... 1
12 9198 Grip, clutch lever ........................... 1
13 9442 Wheel gear control & cable assy.
(Incl. Ref No's. 14, 15, 19, 21,
22 & 23).....................................
1
14 9057 Knob, wheel gear control lever ...... 1
15 1186211 Nut–hex, 5/16-24........................... 2
16 1100068 Screw, hex hd., 3/8-16 x 3/4.......... 2
17 1100243 Lockwasher, 3/8 ............................ 2
18 9445 Engine throttle control & cable ...... 1
19 9202 Ties, plastic.................................... 4
20 9212 Knob, engine throttle lever............. 1
21 1114748 Screw, No. 10-32 x 1/2.................. 8
22 1100240 Lockwasher, No. 10 ....................... 4
23 1186208 Nut, hex hd. No. 10-32 .................. 4
24 9390 Grip, paddle ................................... 2
25 20863 Bail, forward clutch control
(Incl. two Ref No. 24)................. 1
26 20862 Adjuster assy.
(incl. Ref No's. 27 ,28,
29, 30, 38 & 39).........................
1
27 9532 Klip ring......................................... 2
28 20808 Adjuster, Right side ....................... 1
29 20809 Adjuster, Left side.......................... 1
30 9059 Spring, adjuster ............................. 1
31 9522 Nut, rectangular............................. 1
32 9386 Klip ring......................................... 1
33 20831 Rod, forward clutch....................... 1
34 97083 Pin, Clevis...................................... 1
35 9853 Sems Nut....................................... 4
36 20806 Bracket, bail support...................... 2
37 20888 Swivel............................................ 1
38 9432 Bushing ......................................... 1
39 9973 Washer .......................................... 1
40 1100805 Screw, hex hd., 1/4-20 x 3/4.......... 1
41 9811 Nut, 1/4-20 .................................... 1
42 9552 Screw, flanged hex hd.,
self-tapping, 1/4-20 x 1/2........... 2
HANDLEBAR ASSEMBLY AND CONTROL LEVERS
