11
Connecting the TV44
( co n t i n u e d )
E - With Dish 500 Using SW21 Switches
1. Locate your SW21 multiswitches and disconnect the satellite
leads connected to the “TO RECIEVER” terminals. See Fig 17.
2. Connect the satellite leads to the OUT 1 and OUT 2 terminals
on the TV44. See Fig 17.
NOTE: You may need to extend the satellite leads using a barrel
connector and extra RG6 coaxial cable if they are not long enough.
3. Using 2 black 32” antenna cables connect the “TO RECIEVER”
terminals on the SW21 multiswitches to the IN 1 and IN 2
terminals on the TV44 antenna.
See Fig 18.
N OTE: You may need to purchase longer antenna ca b les separa te ly
if the supplied black 32” antenna cables are not long enough.
4. Continue to “Installing the Indoor Diplexers.”
Diplexer
Diplexer
Fig 18.
Fig 17.
Logo Side
Dish Side
Logo Side
Dish Side
