Troy-Bilt 12227 - Manual (Page 29)

Parts List 29
Models 12209, 12210 and 12227
1 * Engine, Recoil Start............................. 1
2 1917326001 Bracket, Belt Cover.............................. 1
3 1100242 Lock Washer, 5/16 .............................. 6
Lock Washer, 5/16 (B)(C) ................... 7
4 1111696 Hex Hd. Screw, 5/16-24 x 1/2 ............ 2
5 1904557 Decal, Hot Surfaces Warning ............. 1
6 1917128 Belt Cover (Incl. Ref. 5)....................... 1
7 9552 Hex Hd. Flange Screw, Self-Tapping,
1/4-20 x 1/2 .................................... 7
8 1186230 Hex Nut, 5/16-18................................. 4
9 50027 Support Washer .................................. 1
10 1916795001 Engine Bracket, Right.......................... 1
11 1138-2 Shim ................................................... A/R
12 9301 Key, 3/16" x 1" ..................................... 1
13 55035 Pulley, Engine Drive (A) ...................... 1
1916531 Pulley, Engine Drive (B)(C) ................. 1
14 1917746 Shoulder Washer ................................ 2
15 1100005 Hex Hd. Screw, 5/16-24 x 1 (B)(C) ..... 3
16 1916794001 Engine Bracket, Left ............................ 1
17 1100799 Hex Hd. Screw, 5/16-18 x 1-1/2.......... 5
18 1916652001 Guard, Belts/Pulleys............................ 1
19 1916726 Forward Belt Guide (B)(C)................... 1
20 9558 Hex Hd. Screw, 3/8-16 x 1-1/2............ 1
21 9090 Forward Idler Pulley ............................ 1
22 1918744 Forward Idler Lever ............................. 1
23 1110108 Lock Nut, 3/8-16 ................................. 1
24 1107382 Flat Washer ......................................... 2
25 9929 Flat Washer ......................................... 1
26 55037 Forward Drive Belt (A) ........................ 1
1916657 Forward Drive Belt (B)(C).................... 1
27 55034 Forward Return Spring........................ 1
29 1916658 Reverse Drive Belt (B)(C).................... 1
30 9944 Belleville Washer................................. 1
31 55031 Transmission Pulley (A)...................... 1
1916532 Transmission Pulley (B)(C)................. 1
32 1916117001 Bracket, Cable Mounting ..................... 1
33 1900766 Decal, Stabilization.............................. 1
34 1186328 Hex Hd. Screw, 5/16-18 x 5/8 ............. 4
35 1100044 Hex Hd. Screw, 5/16-18 x 3/4 ............. 1
36 1107383 Flat Washer, 3/8 .................................. 1
37 1916536 Bushing (B)(C).................................... 1
38 1916578001 Reverse Idler Arm (B)(C) .................... 1
39 1916535 Pulley, Reverse Idler (B)(C) ................ 1
40 1111606 Hex Hd. Screw, 5/16-18 x 2 (B)(C) ..... 1
41 1110107 Lock Nut, 5/16-18 (B)(C) .................... 2
42 1916725 Belt Guide (B)(C) ................................ 1
43 1916724 Reverse Return Spring (B)(C)............. 1
44 1108841 Key, 3/16" x 1-1/2" .............................. 1
45 55036 Spacer (A)........................................... 1
46 55039 Forward Belt Guide (A)........................ 1
47 1100004 Hex Hd. Screw, 5/16-24 x 3/4 (A) ....... 2
REF. PART
No. No. DESCRIPTION QTY.
REF. PART
No. No. DESCRIPTION QTY.
* Contact your local authorized engine service dealer for engine parts and
service. Refer to your engine nameplate for engine model/type number.
(A) For Model 12227
(B) For Model 12209
(C) For Model 12210
A/R – As Required
