Control Panel
MAINS
ON
THERMOSTAT
ON
NORMAL
NORMAL
NORMAL
NORMAL
OVEN & GRILL
TIMER
1. Oven Thermostat Pilot Light
2. Cooker Operation Pilot Light
3. Front left cooking zone control knob
4. Back left cooking zone control knob
5. Back right cooking zone control knob
6. Front right cooking zone control knob
7. Oven function control knob
8. Minute minder
7
6
5
4
2
1
3
The Oven Cavity
Grill element
Oven Light
Accessories
Oven fan
8
Grill trivet
Grill/roasting pan
Removable
handles
