P
PRODUCTS
SI-300
System Interface
Interfacing Capability Options
RF Field Probes
Magnetic and Electric types supported
Emission Positioning Devices
Turntable
Antenna mast/polarizer
Absorption clamp
Immunity Positioning Interfaces
X-Y Probe Positioner
Antenna mast/polarizer
RF Switch Interface
Control Remote Switches
Control Local Switches on Rear Panel
IEEE-488 Computer Interface
Fiber Optic Interface
Communication: 62.5-micron glass
Ordering Information
Product: System
Interface
Model Number:
SI-300
Warranty:
1 year
To place an order or to learn more about the
TDK products that best meet your needs, con-
tact your TDK sales representative:
TDK RF Solutions Inc.
1101 Cypress Creek Rd.
Cedar Park, Texas 78613 USA
Phone: 1-512-258-9478
Fax: 1-512-258-0740
E-mail:
World Wide Web:
www.tdkrfsolutions.com
Rev. 2011-08-02
Electrical/Environmental Specifications
Power Requirements
100-240 VAC, 50-60
Hz, 45 W
Communication Media Fiber optic cable
(ST connectors);
Bi-direction asynchro-
nous serial
Display Resolution
240 x 64 backlit LCD
Channel Capacity
4 fiber channels
RF Field Monitoring
Frequency Range: 10 kHz to 40 GHz
Measurement Range: 0.1 V/m to 1000 V/m
Channels: 4 channel display
Display: X, Y, Z and Resultant
Diagnostic: Error, Low Battery
