2
5.
How to configure and test TricklePower performance of REB-2000 series GPS engine boards?
Ans:
Please refer to “REB-2000 series operational manual”.
http://www.tri-m.com/products/royaltek/manual/reb2000.pdf
6. What are the differences among REB-12R series?
Ans:
The following is the comparison table of REB-12R series:
REB-12R1 REB-12R2 REB-12R5 REB-12R6 REB-12R7 REB-12R30
Connector 20 pin header
/Down
20 pin header
/Down
20 pin header
/Down
20 pin header
/Down
20 pin header
/Up
20 pin header
/Down
RF Connector Female MCX
/ Up
Female MCX
/Up
Female MCX
/Up
Female MCX
/Up
Female MCX
/Right
Female MCX
/Right
Data Retention Power Lithium N/A N/A N/A Super Cap. Super Cap.
Voltage 5V±5% 5V±5% 5V±5% 5V±5% 5V±5% 3.3V±10%
Channels 12
Frequency L1,
1575.42MHz
Protocol NMEA 0183, GPGGA, GPRMC, GPGSA, GPGSV, GPGLL, GPVTG, 9600,8,N,1
Maximum current 180mA
Reacquisition time 0.1 sec.
Hot start (average) 8 sec.
Warm start (average) 38 sec.
Cold start (average) 48 sec.
Accuracy 25m CEP w/o S.A.
Differential input RTCM 104 DGPS
Interface TTL,9600,8,N,1
Update Rate
1Hz
Trickle power N/A
Operation Temperature -40 ~ +85℃
Storage Temperature -55 ~ +100℃
Operating Humidity ≦ 95% Non-condensing
Maximum Altitude 18000m
Maximum Velocity 515m/s
Maximum Acceleration 4G
Weight (g) 19.3
Dimension (LxWxH) 71 x 41 x 7mm
