(E) Symbio 160HD4

Chapter 5: Appendix

Specifications

NOTE:

• This model complies with the specifications listed below.

• Designs and specifications are subject to change without notice.

• This model may not be compatible with features and/or specifications that may be added in the future.

Interface Specifications

• DTVLink and IEEE-1394 compliant.
• AV/C compliant.
• Supports 400 Mb/sec maximum serial bus data transfer rates.
• Two external 6-pin IEEE-1394 ports.
• Hot-plug capable.

Drive Capacity

160 gigabytes (GB)*

* When referring to hard drive capacity, a gigabyte (GB) means one billion bytes. Not all clusters contained in the 160 GB hard drive are useable for

recording because a portion of the drive space is allotted for directory information.

Recording Capacity

High definition: 16 hours max.**
Standard definition: 80 hours max.**

**Actual recording times will vary depending on the bit rate of the program being recorded.

Environmental Conditions

Operating temperature: 41˚ to 95˚ F (5˚ to 35˚ C)
Acoustics (typical) idle mode: 33 dBA average

Power Requirements

AC input voltage: 120V AC +/– 10V
AC input frequency: 50–60 Hz
AC input current: 0.6A max. (RMS)

Dimensions

Height: 2.0 in. (5 cm)
Length: 10.5 in. (22.25 cm)
Width: 8.45 in. (21.13 cm)
