6
The Control Panel
Attention!
If you turn the programme selector dial to another
programme when the machine is working, a warning
message appears for 3 seconds on the display.
3 “spin” button
Press this button repeatedly to change the spin speed, if
you want your laundry to be spun at a speed different
from the one proposed by the washer-dryer or to choose
the
“rinse hold” option. The relevant light will
light up.
Maximum speeds are:
• for cottons: 1200 rpm for the Model WDR 1241 W
1000 rpm for the Model WDR 1041 W
• for synthetics fabrics and Wool: 900 rpm; for
• for delicate fabrics and M INI program 30°: 700 rpm.
“rinse hold” position: when you choose this
option, the machine will not drain the water of the last
rinse, so as not to crease the laundry.
At the end of the cycle, the light of the “start pause”
button goes out, the “end” light illuminates but the door
is locked to indicate that the water must be drained. A
flashing zero appears on the display.
To complete the cycle, there are 2 possibilities:
• Select programme 21 (drain) and then depress the
start pause button: the water is emptied out without
spinning.
• Select programme 22 (spin). Select the spin speed
by means of the relevant button and then depress the
start pause button. The water is emptied out and
the laundry is spun at the selected spin speed.
1 Detergent dispenser drawer
and programme guide
2 Programme selector dial
The selector dial is divided into the following sections:
•
Cottons (from 1 to 7 )
•
Synthetics (from 8 to 12 )
•
Delicates (13 and 14 )
•
Wool (Handwash) (15, 16 and 17)
•
Soak 30, rinses, softener, drain, spin and M INI
program 30° (from 18 to 23)
•
“O” Off = Reset/Switching the machine off
The selector dial can be turned either clockwise or
anticlockwise.
Cotton economy (programme 2) position corresponds
to the ENERGY SAVING programme for cotton and
position “O” Off to Reset programme/Switching off of
the machine.
corresponds to a cold wash.
At the end of the programme the selector dial must be
always turned to position “O” Off , to switch the
machine off .
PROGRAMME
1
2
3
4
5
6
7
8
9
10
11 12 13
14
15
16
17
18
19
20
21
22
23
1 2 3 4 5 7 8 9 10 6
DELICATE
DELICATE
WOOL
WOOL
WOOL cold
SOAK
rinses
softener
drain
spin
MINI program
COTTON
COTTON economy
COTTON
FAST COLOURS
NON FAST COLOURS
COTTON
COTTON DRY
SYNTHETIC
SYNTHETIC
SYNTHETIC
SYNTHETIC
SYNTHETIC DRY
1
2
3
4
5
6
7
8
9
10
11
12
95°
60°
60°
50°
40°
30°
60°
50°
40°
30°
13
14
15
16
17
18
19
20
21
22
23
40°
30°
40°
30°
30°
30°
PROGRAMME
1
2
3
4
5
6
7
8
9
10
11 12 13
14
15
16
17
18
19
20
21
22
23
end
half
load
spin start
pause
option
dry
dry
time
time
wash prewash
intensive
extra rinse
1000
900
700
500
quick
wash
WDR 1041 W
