Door Reversal
1. Disconnect the appliance from the electricity
supply.
2. Remove all loose items, including food. Store
food in a cool place.
3. Make sure a towel or cloth is at the base of
the product to prevent it from slipping.
4. Carefully lean the appliance backwards,
resting the top on a stool, or something
similar, at least 30cm (12") from the floor.
Do not support the appliance on the rear
ventilation grille or condenser.
5. Remove level adjuster (A) from base of
product retaining small cup spacer which is
located around the threaded portion of the
adjuster.
6. Remove the foot / hinge assembly (B) by
removing screws marked (C).
7. Remove the bottom door by lifting it upwards
slightly and carefully sliding it down off the
centre hinge pin (H).
8. Remove the centre hinge (H) by taking out the
fixing screw (J) pull the hinge (H) down out of
the top door being careful to retain the
blanking plug (L) in the front face of the hinge.
9. Remove the top door by carefully sliding it
down off the upper hinge pin (F).
10. Unscrew the upper hinge pin (F) by removing
screw (G) and transfer it to the opposite side
of the cabinet.
11. Using a flat bladed screwdriver remove the
blanking cover (K). Refit cover by clipping it
back on the opposite side.
