223 Series Adaptor panels to Motorola MCS Mobile
3.3 IP223 Setup:
Setup the desired IP223 lines jumpers for Local radio control.
3.3.1 IP223 Jumper settings:
Line 1
Jumper setting
Line 2
J33, J34
“B”=4-wire
J5, J6
J16, J21
“A”=Single Ended
J19, J20
J14
“Hanging on center pin”= 10K Ohm
J24
J3, J9, J11
“A”=Single Ended
J25, J28, J29
J13
“B” High
J27
J17, J22
“B”= 600 ohms
J10, J15
R377
Solder bridge the pads together
R381
