2-1 Quick Start
Quick Start
The steps in this chapter can be followed to quickly prepare the TPA701 MSOP
audio amplifier EVM for use. Using the TPA701 MSOP EVM with the TI
Plug-N-Play Audio Amplifier Evaluation Platform is a quick and easy way to
connect power, signal and control inputs, and signal outputs to the EVM, using
standard connectors. However, the audio amplifier evaluation module can be
used stand-alone by making connections directly to the module pins, and it can
be wired directly into existing circuits or equipment.
The platform switch and jumper settings shown in Table 2–1 are typical for the
TPA701 MSOP EVM. They will cause the TPA701 device to shutdown when
a plug is inserted into platform headphone jack J10.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA701
MSOP EVM
EVM JP6 JP7 JP8 S2 S3
TPA701 Mute X Hi Note 2 X
Notes: 1) X = Don’t care
2) Set S2 to ON when signal conditioning board is installed in U1; set S2
to OFF when no signal conditioning board is installed.
Topic Page
2.1 Precautions 2–2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2–3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2–4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
