PARTS INFORMATION
[email protected] Page 4
TBL-7600
CRANKCASE, FLYWHEEL, IGNITION • FIGURE 2
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
2-3 0901600020 GASKET,CRANKCASE 1
2-5 0721600090 CRANKCASE 1
2-7 8011600020 BEARING,BALL 2
2-8 0441600020 SEAL,OIL 2
2-10 8061600020 SCREW,A 1
2-11 8141600020 SCREW 4
2-12 8401600020 KNOCK PIN 2
2-13 8201600020 PACKING 1
2-19 8021600020 SHIM,CRANKSHAFT V
2-19 8031600020 SHIM,CRANKSHAFT V
2-19 8041600020 SHIM,CRANKSHAFT V
2-19 8051600020 SHIM,CRANKSHAFT V
2-29 1551600080 MAGNETO 1
2-32 1671600080 COIL,IGNITION 1
2-33 8421600020 WIRE 1
2-34 8431600020 WASHER,S 1
2-35 0681600020 KEY,WOODRUFF 1
2-38 2031600020 GROMMET,A 1
2-40 8151600020 BOLT 2
2-41 8291600020 NUT 1
2-54 7981600090 PULLEY ASSY,STARTER 1
2-55 2581600020 RING,STOP 1
2-56 7661600020 SPRING,STARTER PAWL 1
2-57 7651600020 PAWL,STARTER 1
2-58 0321600020 NUT,SPECIAL 1
2-59 8321600020 WASHER,C 2
