Teletext filtering
in accordance with standard ETS 300 472
Entry teletext data
(FBAS) corresp. to ITU-R BT.653-2; lines: 6-22 and 320-335
TV-SCART:
Output
FBAS with RGB, or only FBAS, or only S-VHS (switchable)
VCR-SCART::
Input
FBAS with RGB or S-VHS
Output
FBAS or S-VHS
Serial Interface RS 232:
Type
RS 232 bi-directional
Bitrate
Max. 115.2 Kbit/s
Connection
9-pin D-SUB connector
Function
Pre-programming and updating operational software
PLL-Modulator:
Output range
UHF channels 21 to 69
Antenna input
47….862 MHz
Input impedance
75 Ohm
Antenna output
47…862 MHz
Output impedance
75 Ohm
LNB power supply:
LNB power
Max. 400 mA, double-insulated
LNB voltage vertical
<14.0 V no load, 11.5 V at 400 mA
LNB voltage horizontal
<20 V no load, >17.5 V at 400 mA
LNB switched off in Standby mode
22 kHz-Modulation:
22 kHz, amplitude 0.6 V +/- 0.2 V
Programme memory/ Satellite positions:
No. of programmes user list TV:
999 TV programmes
(F1 to F999)
No. of programmes user list Radio:
999 radio programmes
(r1 to r999)
Number of Programmesl:
Bouquet lists TV/Radio
total of 4000 programmes possible in bouquet lists
Number of active satellite positions:
Max. 4 (DiSEqC 1.0, SAT POSITION/ SAT OPTION)
Total number of satellite position:
32
One home transponder is stored in memory for each of the 32 satellite positions. This trans-
ponder facilitates automatic channel/programme search on each satellite position.
EPG Data:
EPG preview:
Maximum 7 days in advance
Memory capacity:
300 kBytes
Programmable for a maximum of 50 programmes
Timer:
Events
Maximum 128 events, one year in advance
Remote Control System:
RC-5
Sub-system address
8 (SAT 1)
Modulation frequency
36 kHz
Infrared wavelength
950 nm
