Trango Broadband AD2401-24 User Manual
Features, Technical specifications

24
Features
AD2401-24
24dB Parabolic Grid
Antenna
Technical Specifications
Freq. Range
(MHz)
Beamwidth
Gain (dBi)
Feedhorn
Finish
2400 - 2484
10-13º
Dipole
Made in the USA. All specifications
subject to change without notice.
VSWR
1.5:1 (50
Ω
)
Copyright © 1997-99 Trango Systems. All rights reserved.
Features
· 24dB linear patch antenna
· 2400-2484 MHz
· Beamwidth: 10-13º
· Polarization: linear
For more information contact:
Trango Systems
9939 Via Pasar · San Diego, CA 92126
Phone: (858) 653-3900 • Fax: (858) 621-2725
Powdercoat white
Dimensions
Connector
23.5” x 15” x 39.5”
(assembled)
TNC to SMA on a
24” cable
Mounting
Provisions
Weight
Pole up to 2 3/8”,
hardware included
5.5 lb
