7.5 and 18 volts,
protecting all IEEE
802.3 pins.
DB15 ethernet AUI
protector.
750 amps
DHUB: RJ45, 8-port
ethernet, token ring
RS422/423/485, AS400/
Sys3x protector for hubs,
repeaters, terminal
servers, MUXs, MAUs,
etc.*
DHUB-18V: RJ45, 8-port
RS 232 protector for
multiport serial devices.*
RJ45/RJ11 protector for
100Base-T4, RS-232 on
twisted pair (wires 1-8) or
ISDN “S/T” interfaces.
Supplied with 4” RJ45
patch cable.
RJ45 100Base-T, 10Base-T,
Token Ring, RS422, AS400/
Sys3x protector for NICs,
hubs, routers, etc. Supplied
with 4” RJ45 patch cable.
RJ45/RJ11 protector for
nonspan powered T-1
equipment , digital data
service CSUs/DSUs, ISDN
“U” interfaces or other
digital lines. Supplied
with 4” RJ45 patch cable.
RJ45/RJ11 for modems,
answering and fax
machines. Supplied with
4” RJ11 patch cable.
Serial DB9 RS-232
protector for male or
female ports of data
terminal and computing
equipment including
PCs, modems, etc. (any
male or female 9 pin
port). Male/Female
genders are reversible
with reversible
thumbscrews.
60 volts, protecting wires
1-8.
7.5 volts, protecting
wires 1-8 on all ports.
18 volts, protecting wires
1-8.
7.5 volts, protecting
wires 1-8.
260 volts, protecting
center 4 wires (2 CO-
lines).
18 volts, protecting
pins 1-9 and chassis.
18 volts, protecting
wires 1-8 on all ports.
340 amps
750 amps
340 amps
750 amps
200 amps
250 amps
340 amps
Model:
DHUB
DHUB-18V
DRS232
DNET1
DSUT1CSU
DTEL2
DB9
DB15AUI
SPECIFICATIONS All surge suppressors listed have component response times of less than 1 picosecond.
* Supplied with eight 4” RJ45 patch cables.
Description:
Nominal
Clamping Voltage: Peak Pulse
Current:
