Trek 08 - Manual (Page 2)

HiFi HiFi 29er
HiFi, GS, Plus,
dLX, dLX GS (RP2)
Pro, Carbon, Carbon Pro (RP23) HiFi Plus 29, dLX 29
(RP2)
HiFi Pro 29(RP23)
Travel (mm) 116 116 100 100
Stroke (mm) 50 50 50 50
Sag (%) 25 25 25 25
Sag (mm) 12 12 12 12
Rider
(lbs / kg)
Spring
(psi) Rebound
Spring
(psi) Rebound
Platform
Number
Setting
Spring
(psi) Rebound
Spring
(psi) Rebound
Platform
Number
Setting
100 / 45 75
7 clicks out
from slow
75
7 clicks
out from
slow Start in #2
Position.
Adjust per
desired
efficiency
(3 for more
platform,
1 for more
active)
65
7 clicks
out from
slow
65
7 clicks
out from
slow Start in #2
Position.
Adjust per
desired
efficiency
(3 for more
platform,
1 for more
active)
110 / 50 83 83 70 70
120 / 55 90 90 75 75
130 / 59 98 98 80 80
140 / 63 105 105 85 85
150 / 68 113
5 clicks out
from slow
113
5 clicks
out from
slow
90
5 clicks
out from
slow
90
5 clicks
out from
slow
160 / 73 120 120 95 95
170 / 77 128 128 100 100
180 / 82 135 135 110 110
190 / 86 143 143 115 115
200 / 90 150 150 120 120
210 / 95 158
3 clicks out
from slow
158
3 clicks
out from
slow
125
3 clicks
out from
slow
125
3 clicks
out from
slow
220 / 100 165 165 130 130
230 / 104 173 173 135 135
240 / 109 180 180 140 140
250 / 113 188 188 145 145
sag (mm)
35
25
12
5
0
30 HiFi
HiFi 29er
20
15
GARY FiSHER SuSPENSiON CARd
10
HiFi HiFi 29er
HiFi, GS, Plus,
dLX, dLX GS (RP2)
Pro, Carbon, Carbon Pro (RP23) HiFi Plus 29, dLX 29
(RP2)
HiFi Pro 29(RP23)
Travel (mm) 116 116 100 100
Stroke (mm) 50 50 50 50
Sag (%) 25 25 25 25
Sag (mm) 12 12 12 12
Rider
(lbs / kg)
Spring
(psi) Rebound
Spring
(psi) Rebound
Platform
Number
Setting
Spring
(psi)
Rebound
Spring
(psi) Rebound
Platform
Number
Setting
100 / 45 75
7 clicks out
from slow
75
7 clicks
out from
slow Start in #2
Position.
Adjust per
desired
efficiency
(3 for more
platform,
1 for more
active)
45
7 clicks
out from
slow
45
7 clicks
out from
slow Start in #2
Position.
Adjust per
desired
efficiency
(3 for more
platform,
1 for more
active)
110 / 50 83 83 50 50
120 / 55 90 90 65 65
130 / 59 98 98 72 72
140 / 63 105 105 80 80
150 / 68 113
5 clicks out
from slow
113
5 clicks
out from
slow
90
5 clicks
out from
slow
90
5 clicks
out from
slow
160 / 73 120 120 100 100
170 / 77 128 128 110 110
180 / 82 135 135 115 115
190 / 86 143 143 118 118
200 / 90 150 150 120 120
210 / 95 158
3 clicks out
from slow
158
3 clicks
out from
slow
125
3 clicks
out from
slow
125
3 clicks
out from
slow
220 / 100 165 165 135 135
230 / 104 173 173 140 140
240 / 109 180 180 145 145
250 / 113 188 188 150 150
sag (mm)
35
25
12
5
0
30
HiFi
HiFi 29er
20
15
GARY FiSHER SuSPENSiON CARd
10
