Model #: P516-001-HR
1-ft. High-Resolution SXGA/UXGA Monitor Y Splitter Cable, (HD15M / 2xHD15F)
Highlights
Splits the SXGA/UXGA signal providing simultaneous display of the same
image on two monitors
HD15 Male splits to 2 HD15 Female, 1 ft.
Description
Tripp Lite's 1 ft. SXGA/UXGA Monitor "Y" Splitter cable provides an inexpensive alternative for splitting the video signal from your PC's VGA port to 2
High-Resolution monitors that use standard 15-pin plugs. 75-ohm coax conductors used for RGBHV signals allow for use with monitors with up to
1600 x 1200 resolutions. Perfect for laptops to display on a separate, larger monitor. Use for short distance applications only. For applications that
require longer distances and highest resolution, see Tripp Lite
Applications
Presentations that require multiple monitors for easier viewing
System Requirements
PC/MAC with 15-pin Female VGA CPU port
Package Includes
1-ft. SXGA/UXGA Hi-Res Splitter Cable, HD15M to 2 x HD15F
Features
HD15 Male to 2 x HD15 Female w/Hex Nuts
RGB cable construction supports resolutions up to 1600 x 1200
Molded, double-shielded construction for maximum EMI/RFI protection
Two monitors display the image from one PC
Inexpensive solution for presentations
Specifications
OVERVIEW
Intended Application
Connecting Peripherals
Cable Type
MONITOR
Display Style
Splitter
