Model 1439 Specifications
Overall Dimensions: ............................24" (610 mm) Wide x
.............................................................25" (635mm) Deep x
.............................................................13-3/8" (340 mm) High
Installed Weight: ................................. 85 lb. (38.5 kg)
Shipping Weight: .................................95 lb. (43.0 kg)
Exterior Finish: .................................... Stainless Steel Front, Sides and Top
Shortening Container (Vessel): ........... One-Piece Deep Drawn Stainless Steel,
.............................................................30 Ib Shortening Capacity (2-15lb Fat Wells)
Construction: .......................................Formed and Welded Steel
Thermostat: ........................................ Adjustable from 250°F to 400°F (121.1 °C to 204.4°C)
Model 1439 Electrical Specifications
3 PHASE LOADING NOMINAL AMPS PER LINE WIRE MINIMUM SUPPLY WIRE
TOTAL kW PER PHASE 3 PHASE 1 PHASE SIZE (AWG)
VOLTS kW X-Y Y-Z X-Z X Y Z TOTAL 1 PHASE 3 PHASE
208V 11.4 5.7 -- 5.7 47.5 27.4 27.4 -- -- 4
240V 11.4 5.7 -- 5.7 41.2 23.8 23.8 47.5 4 6
480V 11.4 5.7 -- 5.7 20.6 11.9 11.9 23.8 10 10
Note: All supply wire, to be rated 600V, 90°C
Optional Accessories:
• Extra Stainless Fat Well - 1408W
• Full Size Basket, Right - ACBF1439
• 4 Wire, 3’ Cord with Plug, NEMA Standard 15-50P - C1550
SECTION 1 - DESCRIPTION
