Tech 21 TRADEMARK 10 - Manual (Page 6)

Trademark 10 Hook-Up Diagrams
SEND RETURN
STEREO EFFECTS
PROCESSOR
INPUT RETURN
L R INPUT
TRADEMARK 10 TRADEMARK 10
STEREO HOOK-UP
STEREO EFFECTS
PROCESSOR *
INPUT
L R
INPUT
SANSAMP
XLR
DIRECT
OUT
XLR
OUT INPUT
TO CHAIN
OR TO P.A.
POWER ENGINE 60
XLR
OUT INPUT
TO CHAIN
OR TO P.A.
POWER ENGINE 60
Use a line matching
transformer, such as
Shure Model #A95UF,
or equivalent
* When available,
it is preferable
to use XLR jacks
TRADEMARK 10
STEREO HOOK-UP with POWER ENGINE 60s
SEND RETURN
TRADEMARK 10 TRADEMARK 10
INPUT
CHAINING TRADEMARK 10s
SANSAMP XLR
DIRECT OUT
XLR
IN
XLR
OUT
XLR
IN
XLR
OUT
INPUT
POWER ENGINE 60 POWER ENGINE 60
TO CHAIN OR TO P.A.
TRADEMARK 10
CHAINING TRADEMARK 10 with POWER ENGINE 60(s)
TRADEMARK 10
INPUT
REMOTE VOLUME CONTROL HOOK-UP
SEND RETURN OUTPUT INPUT
With POWER AMP and SPEAKER CABINET
SEND INPUT SPEAKER OUT
TRADEMARK 10
INPUT
POWER AMP
TO 2 X 12 OR 4 X 12
SPEAKER CABINET
