17
Model 12215
Parts List
1 1918303 Handlebar Assy. (Incl. Refs. 2, 3, 4 & 5) ....... 1
2 1909936 Decal - On/Off Ignition Switch ....................... 1
3 1909939 Decal - Starting Stabilization ......................... 1
4 1918221 Decal - Throttle Lever Operation.................... 1
5 1917451 Handlebar Grip, PVC...................................... 2
6 1918123 Throttle Lever and Cable................................ 1
7 1750608 Pan Hd. Screw, #10-16 x 1-1/2 ..................... 1
8 1731025 Saddle Hd. Screw, 5/16-18 x 2 ...................... 2
9 1909775 Spacer, Throttle Lever ................................... 1
10 1983718 On/Off Ignition Switch ................................... 1
10A 1981012001 Bracket - On/Off Ignition Switch ................... 1
11 1766503 Phillips Hd. Screw, #12-24 ............................ 1
12 1918088 Wire Assy. - On/Off Ignition Switch ............... 1
13 1763682 Plastic Wire Tie.............................................. 6
14 1918120001 Lower Handlebar - Left-Side.......................... 1
15 1918121001 Lower Handlebar - Right-Side ....................... 1
16 1909720 Foam Sleeve .................................................. 1
17 1983663 Hex Hd. Screw, 1/4-20 x 5............................. 2
18 1107381 Flat Washer, 1/4-20 ....................................... 2
19 1817146 Hex Locknut, 1/4-20...................................... 5
20 * Engine ........................................................... 1
21 1909487 Clutch Rotor and Washer .............................. 1
22 1918309 Tine Shield (Incl. Refs. 23, 24, 25 & 26) ....... 1
23 1918061 Decal - Logo .................................................. 1
24 1904553 Decal - Warning, Rotating TInes.................... 1
25 1904549 Decal - Warning, Hot Surfaces ...................... 1
26 1904552 Decal - Caution, Operation Hazards ............... 1
27 1186292 Hex Hd. Screw, #10-24 x 1/2......................... 2
28 1186387 Flange Locknut, #10-24................................. 2
29 1100241 Lock Washer, 1/4-20 ..................................... 4
30 1100807 Hex Hd. Cap Screw, 1/4-20 x 2...................... 4
31 1909540 Outer Tine - Right-Hand Side ........................ 1
32 1909539 Inner Tine - Right-Hand Side......................... 1
33 1909712 Outer Tine - Left-Hand Side........................... 1
34 1909711 Inner Tine - Left-Hand Side ........................... 1
35 1909680001 Wheel Bracket ............................................... 1
36 90077 Carriage Bolt.................................................. 1
37 1909835 Knob.............................................................. 1
38 1100069 Hex Hd. Screw, 1/4-20 x 1............................. 3
39 1909517001 Axle ............................................................... 1
40 1917754 Wheel ............................................................ 2
41 1729775 E-Ring ........................................................... 4
42 1904321 Ring Lock Pin ................................................ 2
43 1981022010 Tine Hood Cover............................................ 1
44 1763767 Knob.............................................................. 2
45 1177038 Lock Washer, 5/16......................................... 2
EDGER ATTACHMENT
46 1903777 Edger Wheel .................................................. 1
47 1903778 Bushing - Short ............................................ 1
48 1983648 Bushing - Long ............................................. 2
49 1915054 Edger Tine ..................................................... 1
OPTIONAL ATTACHMENTS
---- 12575 Power Lawn Rake Attachment....................... 1
---- 12574 Lawn Aerator Attachment .............................. 1
Ref # Part # Description Qty. Ref # Part # Description Qty.
* Order parts from your local authorized engine dealer. Refer to engine nameplate
for model/type number.
