TP-Link TL-POE150S - Manual (Page 10)

5
)
Note:
¾ Do not mistake the power port of the TL-POE150S and
TL-POE10R when choosing the Scheme 2, or else it will
cause serious damage to your network device.
¾ If you want to know more details about TL-POE10R Splitter,
please refer to “TL-POE10R User Guide” on our website
http://www.tp-link.com.
Appendix: Specifications
Normal
Standards
IEEE 802.3, IEEE 802.3u, IEEE
802.3af
PoE Port
Ports
LAN Port
100BASE-TX / 10BASE-T dual purpose
port
Cabling Type RJ45 CAT 5 UTP cable
LED PWR
Safety &
Emissions
FCC, CE
Environmental and Physical
Operating Temp
0℃~40℃ (32℉~104℉)
Storage Temp -40℃~70℃ (-40℉~158℉)
Operating Humidity 10%~90% RH, Non-condensing
Storage Humidity 5%~90% RH, Non-condensing
