TRENDnet TK-401R - Manual (Page 9)

7
Port Selection: Push Button and Hot-Key Commands
Auto-Scan Intervals:
5 ~ 99 seconds
External AC Power Adapter:
9V DC, 1A (TK-801/TK1601 only)
Management:
TK-401R: 4 computers
TK-801R: 8 computers
TK-1601R: 16 computers
Console Port Connectors:
(all female)
1 x PS/2 keyboard 6-pin mini din
1 x PS/2 mouse 6-pin mini din
1 x VGA HDB15 15-pin
PC Port Connectors:
(all female)
4/8/16 x PS/2 keyboard 6-pin mini din
4/8/16 x PS/2 mouse 6-pin mini din
4/8/16 x VGA HDB 15-pin
VGA Resolution:
1920 x 1440
Specifications
Weight:
TK-401R : 835g (1.84lb.)
TK-801R : 1.9 kg (4.2 lbs)
TK-1601R : 2.65 kg (5.85 lbs)
0ºC ~ 40ºC (32ºF ~104ºF)
Operating Temperature:
-20ºC ~ 60ºC (-4ºF ~ 140ºF)
Storage Temperature:
0%~90%, Non-Condensing
Humidity:
FCC and CE
Certifications:
Dimensions:
TK-401R
202 x 104 x 45mm (8.0 x 4.1 x 1.8 in.)
TK-801R
407 x 165 x 45mm (16.0 x 6.5 x 1.8in.)
TK-1601R
406 x 165 x 85 mm (16.0 x 6.5 x 3.4 in.)
