C-44 Elo Touchmonitor User Guide
Touchmonitor Specifications
Model ET1229L
LCD Display 12.1” TFT Active Matrix Panel
Display Size 246(H) x 184.5(V) mm
Pixel Pitch 0.3075(H) x 0.3075(V) mm
Display Mode VGA 640 x 350 (70 Hz)
VGA 720 x 400 (70Hz)
VGA 640 x 480 (60 / 72 / 75Hz)
SVGA 800 x 600 (56 / 60 / 72 / 75Hz)
Native SVGA 800 x 600
Max. Resolution SVGA 1024 x 768
Contrast Ratio 450 : 1 (typical)
Brightness 315 Cd/m 2 with AT 280 cd/m 2 , IT 315 cd/m 2 , IR 315 cd/m 2
Response Time Tr=20 msec, Tf=40 mesc;
Display Color 262K
Viewing Angle (L/R)= -65
o
/+65
o
(typical), (U/D) +60
o
/-45
o
(typical);
Input Signal Video R.G.B. Analog 0.7V peak to peak
Sync TTL Positive or Negative
Signal Connector 15 Pin Mini D-Sub
Front Control Power on / off with LED, Menu / Select (up, down),
Adjustment(+, -)
Contrast, Brightness, V-Position, H-Position,
Recall Defaults, ColorTemperature, Volume, Sharpness,
Phase, Clock, OSD H-Position, OSD V-Position,
OSD OSD Time, Auto Adjust, OSD Language,
Image Information
Plug & Play DDC1 / 2B
Touch Panel (optional) AccuTouch, IntelliTouch and CarrollTouch
Power Adapter Input AC 100-240V, 50-60Hz, Output DC 12V/5A (max.)
Operating Conditions Temp 0 o C ~ 40 o C (41 o F ~ 95 o F)
Humidity 20% ~ 80% (No Condensation)
Altitude To 12,000 Feet
Dimensions (HxWxD) 310 x 312 x 146mm
Weight (Net) 19.84lbs., monitor weight 11.90 lbs.
Certifications UL,C-UL, FCC-A, CE, TUV-GS, VCCI, MPRII, C-TICK
