Key Features:

Compact, Lightweight, 139 dB SPL

Fast, Simple Integrated Rigging

Footprint Identical to XLC-127+ and

XLC-118

Optional Adapter Grid for use with XLD281

2 x DVX3150 Transducers

Weather Resistant

XLC-215

High-Output

Dual 15” Subwoofer

Line-Array Element

General Description:

EV engineers have defined a new group of compact
line array elements, the X

LC

. It is comprised of three

components - X

LC

127+ full range with ND6-16 large format

high frequency transducers and two subwoofer systems.
The X

LC

118 sub cabinet uses an EVX-180B, and the X

LC

215 uses two DVX3150’s. Both are true sub-bass systems
designed for high-level, extended low frequency output.
They share the same enclosure footprint and rigging is
identical to that of other X

LC

systems, allowing flexible

subwoofer integration with full range arrays requiring
extended low frequency response. With a height 1.5
times that of the X

LC

127+, a subwoofer array can be

flown side by side with column appearances similar to
the main array using a ratio of 2 subs for every 3 full
range boxes. Subwoofer systems can also be placed at
the top or bottom of full range arrays for seamless arrayed
4-way system integration. Designed for use in groups of
two or more the Subwoofer delivers predictability and
control. Combined with an advanced integrated rigging
system, one-man installations are a reality. The
subwoofer systems can also be ground stacked. Ideal
for applications ranging from live reinforcement to
performing arts venues to houses of worship to sports
facilities, X

LC

gives you the power to make it happen. X

LC

can deliver unprecedented performance, particularly in
difficult acoustical environments.
