Specifications
The 750 specifications are detailed in brief and then subsequently in more detail.
In the detailed version, we attempt to explain the significance of each
specification.
The correlation between published specifications and sonic quality can be
unreliable. A list of numbers reveals virtually nothing. All technical
measurements must be subject to qualitative as well as quantitative
interpretation. M easurements of the 750 reveal excellent results by any
standards. Tested at 115V and 230V after a 10 minute warm up period.
Specifications
In Brief
Rated Power Output:.................................................................. 750W
RMS
into 8Ω
( continuous, driven from 20Hz-20kHz at < 0.040% THD)
............................................................................................... 1300W
RMS
into 4Ω
( continuous, driven from 20Hz-20kHz at < 0.070% THD)
Frequency Response:.......................................................... 5Hz – 40kHz ±0.25dB
Total Harmonic Distortion
( THD+N)
Typically:.....................................................................0.008%, @ 1kHz into 8Ω
20Hz to 20kHz: .......................................................................<0.040%, into 8Ω
Voltage Gain: .............................................................................................. 34.3dB
Dynamic Headroom
( rated with music)
:............................................................>1.1dB
Voltage Swing: ............................................................................................322V
p-p
M aximum Current Output:.............................................................................160A
Damping Factor:.................................................................>700, @ 1kHz into 8Ω
Signal to Noise Ratio
Rated Output ( unweighted) :............................................................................ 100dB
Input Sensitivity
Unbalanced:.............................................................................................1.5V
RM S
Balanced: .............................................................................................±0.78V
RMS
Input Impedance
Unbalanced:.................................................................................................22kΩ
Balanced: ....................................................................................................3.3kΩ
Smoothing Capacitance:...........................................................................60,000µF
Driver Stage:............................................................................................... Class A
Output Stage: ........................................................................................Class A/AB
Audio Inputs
Unbalanced:..............................................................................1 RCA connector
Balanced: .................................................................................. 1 XLR connector
Audio Outputs:.....................................................2 pairs of speaker binding posts
Other Connections
1 x IEC AC mains input receptacle
1 x 3.5mm “mini” jack for master remote input (5 – 12V DC)
1 x 3.5mm “mini” jack for slave remote output (12V DC)
