OWNER’S MANUAL
TABLE OF CONTENTS
Foreword . . . . . . . . . . . . . . . . . . . . . . .2 Assembly Instructions . . . . . . . . . . . . .4-5
Safety Symbols . . . . . . . . . . . . . . . . . . .2 Operating Instructions . . . . . . . . . . . . . .6
Product Description . . . . . . . . . . . . . . . .2 Maintenance . . . . . . . . . . . . . . . . . . . . .7
Safety Instructions . . . . . . . . . . . . . . .3-4
FOREWORD
This Owner’s/Operator’s Manual is designed to familiarize the operator with the various features and
component parts of the equipment and to assist with the assembly, operation and maintenance of the
product.
It is essential that any operator of this product reads and understands the contents of this manual
before using the product.
Important safety instructions will be identified by the following safety symbol:
Failure to comply with the instructions in this manual may result in serious injury or death.
For additional assistance, contact any local authorized Tanaka dealer or contact Tanaka USA at 1-888-482-
6252.
MANUAL SAFETY SYMBOLS
Throughout this manual and on the product itself, you will find safety alerts and helpful information
messages preceded by symbols or key words. The following is an explanation of those symbols and key
words and what they mean to you.
This symbol accompanied by the words WARNING and DANGER calls attention to an act or
condition that can lead to serious personal injury to the operator or bystanders.
1 1 1 1 1
2
2 2 2 2
PRODUCT DESCRIPTION
1. Sweeper Belt
2. Gearcase
3. Outer Tube (Shown for reference only)
4. Sweeper Drum
- 2 -
4 4 4 4 4
