Model #: EZA-035-P
35-ft. Easy Pull Long-Run Display Cable - Type-A Analog Plenum Trunk Cable
Highlights
Versatile trunk cable allows for a variety of connection options
Plenum-rated jacket to comply with local fire codes
At a diameter of 7/8 in., it easily pulls through conduit or confined spaces using
the included end cap with integrated pull tab
High quality RGB style VGA cable supports resolutions up to 1600 x 1200
Description
Tripp Lite's EZA-035-P 35 ft. Easy Pull VGA Plenum Trunk Cable makes pulling video cable through conduit or confined areas a breeze.
Plenum-rated jacket complies with local fire codes. Threaded ends feature screw on pull-caps, which can be attached to fish tape. Choose from a
variety of connector choices that easily screw on to the threaded ends of the trunk cable. Trunk cables are available in 35 ft., 50 ft. and 100 ft.
lengths, both PVC and plenum rated. Cable ends are colored-coded green to denote VGA applications (Digital trunk cables are Yellow). Cable
features triple-shielded construction with 75 ohm coax conductors for RGBHV signals supporting resolutions up to 1600 x 1200.
Applications
Use where standard VGA cables won't fit, such as conduit or confined wall or ceiling spaces
Package Includes
Easy Pull Type-A VGA Analog Plenum Trunk Cable, 35 ft.
Features
Eliminates the need to field terminate VGA connectors
Plenum-rated jacket to comply with local fire codes
Detachable, screw-on connectors
At a diameter of 7/8 in., it makes pulling long cables fast and easy
Protects entire cable from strain, dirt, debris and damage
Choose from a variety of connector combinations for the perfect fit
Available in 35 ft., 50 ft. and 100 ft. lengths, both PVC and plenum rated
Specifications
OVERVIEW
Intended Application
Home Theater/AV, Connecting Peripherals
Cable Type
VIDEO
Display Style
Easy Pull
INPUT
Cable Length (ft.)
35
