DIMENSIONAL DATA
3
YCZ036,050,060F OUTLINE – BACK
MODEL
CORNER WEIGHT (LBS)
NET
UNIT
WEIGHT
(LBS)
A
B
C
D
E
F
G
H
J
K
L
M
N
P
W1
W2
W3
W4
YCZ036F 161 106
104
157
528
64
36 29-3/16 18-9/16 11-1/16 6-9/16 11-1/8
17
18-1/2 25-1/2 17-1/2
10
3
8-3/4
YCZ050F 172 121
137
196
626
65-1/8 45
33-3/8 21-1/16 15-1/16 4-15/16 9-1/8 21-15/16
24
26-1/2
20
14
3-1/2 8-5/16
YCZ060F 195 129
132
199
656
22-3/4 25-1/2
