PARTS LIST
No. Parts No. Description No. Parts No. Description
1 6038-MD1402 HOUSING (L) 16 6SDABB04-18 SCREW
2 6038-MD1401 HOUSING (R) 17 6022-MD1401 MICRO SWITCH
3 6056-MD1401 KNOB 18 6024-MD1401 SPRING
4 6068-MD1401 VACUUM DOOR 19 6024-MD1402 SPRING
5 6114-MD1401 PUSH ROD 20 6041-MD1401 TERMINAL BLOCK
6 6124-MD1401 SHAFT SLEEVE 21 6017-MD1401 AIR COLLECTOR
7 6134-MD1401 BUTTON 22 6279-MD1401 VACUUM BAG
8 6154-MD1401 VACUUM BAG ADAPTER 23 6NHZI5/16-24 NUT
9 6169-MD1401 FAN 24 6097-MD1401 LABEL (R)
10 6129-MD1401 UPPER VACUUM TUBE 25 6097-MD1402 LABEL (L)
11 6129-MD1402 LOWER VACUUM TUBE 26 6052-MD1401 LABEL
12 6129-MD1403 REGULAR NOZZLE 27 6052-MD1402 LABEL
13 6129-MD1404 CONCENTRATOR NOZZLE 28 6013-MD1401 ISOLATOR
14 6228-MD1401 SWITCH ASS'Y 29 6227-MD1401 CUSHION
15 6099-MD1401 MOTOR ASS'Y
