Specifications
Inputs Inputs Inputs Inputs Two electronically balanced nominally 0db
Impedance Impedance Impedance Impedance 10 kOhm
Outputs Outputs Outputs Outputs Four electronically balanced nominally 0db
Min. Load Min. Load Min. Load Min. Load 600 Ohm
Max. Level Max. Level Max. Level Max. Level +19dBu into 2kOhm load
Frequency Resp Frequency Resp Frequency Resp Frequency Resp. ± 0.5dB 20Hz - 20kHz
Dynamic Range Dynamic Range Dynamic Range Dynamic Range 110dB (typ.) 20Hz -20kHz unweighted
Distortion Distortion Distortion Distortion < 0.02% @ 1kHz, +18dBu
Maximum Delay Maximum Delay Maximum Delay Maximum Delay up to 42 ms (increment 21
µ
s)
Output gain Output gain Output gain Output gain adjustable -15dB to +15dB in 0.5dB steps and mute
Bass Boost Bass Boost Bass Boost Bass Boost shelf adjustable ± 6dB in 0.5dB steps
Limiters Limiters Limiters Limiters threshold adjustable over an equivalent voltage range of 30 dB range, in 0.5dB steps
Display Display Display Display 2 x 20 character backlit LCD
Input LED Input LED Input LED Input LED Two per input, signal at -24dBu and digital clip
Limiters LED Limiters LED Limiters LED Limiters LED One per output
Connectors Connectors Connectors Connectors
Inputs
3 pin female XLR
Outputs 3 pin male XLR
Mains 3 pin IEC
Power Power Power Power 100 to 240V ± 10% @ 50/60Hz
Consumpt Consumpt Consumpt Consumption ion ion ion 6.5 watts.
Weight Weight Weight Weight 2.3 kg net (3.5 kg shipping)
Size Size Size Size 1.75”(1U) x 19” x 6.4” (44mm x 482mm x 162 mm) excluding connectors
Due to continuing product improvement the above specifications are subject to change.
