Page 15
Product Information
Switch Off
OFF
-
-
< 1W
Off
This monitor is
E
NERGY
S
TAR
®
compliant.
A
s an
E
NERGY
S
TAR
®
P
artner,
PHILIPS
has
determined that this product meets the
E
NERGY
S
TAR
®
guidelines for energy efficiency.
Physical Specifications
• Dimension (WxHxD) *
425 x 432 x 210 mm
• Weight
7.3 kg
• Tilt / Swivel
-5° ~ 25° / + - 65°
• Height adjustment rang
130 mm
• Power supply
100 — 240 VAC, 60 - 50 Hz
• Power consumption
42.5W (typ. without USB) / 52.5 W (typ. with USB)
• Temperature
5° C to 40° C (operating)
-20° C to 60° C (storage)
• Relative humidity
20% to 80%
• System MTBF
50K hours (excluding CCFL 40K hours)
• Cabinet color
190P6EG: Light Gray
190P6EB: Black
190P6ES: Silver
* This data is subject to change without notice.
* Resolution 1280x1024, standard size, brightness max., contrast 50%, 6500° K, full white pattern, without audio/USB.
Pin Assignment
The digital only connector contains 24 signal contacts organized in three rows of eight contacts. Signal pin
assignments are listed in the following table:
Pin
No.
Signal
Assignment
Pin
No.
Signal
Assignment
Pin
No.
Signal
Assignment
1
T.M.D.S. Data2-
9
T.M.D.S. Data1-
17 T.M.D.S. Data0-
2
T.M.D.S. Data2+
10
T.M.D.S. Data1+
18 T.M.D.S. Data0+
3
T.M.D.S. Data2/4
Shield
11
T.M.D.S. Data1/3
Shield
19
T.M.D.S. Data0/5
Shield
4
No connect
12
No connect
20 No connect
5
No connect
13
No connect
21 No connect
