PARTS INFORMATION
[email protected] Page 9
TBL-7800
THROTTLE LEVER - TBL-7800R • FIGURE 6
ITEM PART NUMBER DESCRIPTION QTY COMMENTS
6-1 8713190690 THROTTLE LEVER ASSY,R 1
6-2 2483190620 GRIP,R 1
6-3 2623190680 GRIP,L 1
6-4 8063190620 SCREW,A,4x14 5
6-5 2633190620 THROTTLE LEVER 1
6-6 2493190620 LEVER 1
6-7 3393190620 SHAFT,LEVER 1
6-8 2403190620 WASHER 1
6-9 8443190620 SPECIAL WASHER 1
6-10 2403190520 WASHER 1
6-11 99354006002 RING,STOP 1
6-12 1621600520 SWITCH,STOP 1
6-13 2621600520 SPRING,STOP SWITCH 1
6-14 8073190620 SCREW,B,4x10 1
6-15 1731600580 CORD 1
6-16 1741600580 CORD 1
6-17 8853190680 WIRE,THROTTLE 1
6-18 1640709400 TUBE,7x940 1
6-19 4653190620 BOLT,WING 1
6-20 99153060013 NUT,CAP 1
6-21 2293190620 CLAMP 1
