Two-wide trapezoidal flybar FB-880/2W
TOPVIEW
BOTTOM VIEW
ENCLOSURE
SUSPENSION
TAB(WIDE)
ENCLOSURE
SUSPENSION
TAB (NARROW)
TILT STRAP
POINTS
The FB-880/2W two-wide flybar is a fixed angle double bar designed to fly two vertical
columns of cabinets up to four deep per column. It provides alternative cabinet suspension
tabs and tilt strap points for narrow or wide configurations (when flying more than two boxes
deep the wide configuration allows for the additional amount of kelp required).
The FB-880/2W has a net weight of 18 kgs.
