Tripp Lite B022-016 User Manual
Page 23
23
Upgrade Succeeded
After the upgrade has completed, a screen appears to inform you that the procedure was successful:
Click Finish to close the Firmware Upgrade Utility.
Upgrade Failed
If the upgrade failed to complete successfully, a dialog box appears asking if you want to retry. Click Yes
to retry. If you click No, the Upgrade Failed screen appears:
Click Cancel to close the Firmware Upgrade Utility. See the next section, Firmware Upgrade Recovery,
for how to proceed.
Firmware Upgrade Recovery
A firmware upgrade recovery is required in any of the following situations:
• When you invoke Firmware Upgrade Mode (see page 22), but decide not to proceed with the upgrade.
• When the main board firmware upgrade fails.
• When the I/O firmware upgrade fails.
200707121 93-2463 KVM Switch Update.qxd 7/31/2007 2:44 PM Page 23
