Switch box and joystick 5101e – Tiger Products Co., Ltd JD 5083E User Manual
Page 117
Parts Section 5-19
ITEM
PART NO.
QTY.
DESCRIPTION
1
06340031
1
MT,BRKT,JYSTK,JD5101E
2
33691
1
JOYST,4AXIS,RH,DF,W/SUB-D CONN
3
06770022
1
CAN,JYSTK,TRUCKAT,4WD
4
06520019
2
MOUNT,RAM BALL,1 1/2",FLANGE
5
06520290
1
MOUNT,RAM,BALL,DBL,1 1/2
6
06520020
2
MOUNT,RAM,ARM,1 1/2x4 5/8,STD
7
06400882
1
RING,BOLT,MNT,JYSTK
8
23113
2
CAPSCREW,10MMX30MM(1.5 PITCH)
9
32990
6
SCREW,MACHINE,10-32X1/2,RD HD
10
32829
4
SCREW,MACHINE,10-32X3/4,FLATHD
11
33693
1
CBL,EXT,4FT,JOYST,W/SUB-D CONN
12
06510196
1
SWITCHBOX,DF,BOOM,PVEA
13
34264
1
SWITCHBOX MOUNT,JD5520
14
34265
1
SWITCHBOX BRACE,JD5520
15
34266
1
SWITCHBOX STRAP,JD5520
16
25188
2
CAPSCREW,10MMX15MM(1.5 PITCH)
17
22016
2
FLATWASHER,3/8,GR8
18
21529
7
CAPSCREW,1/4 X 3/4 NC
19
21527
3
NYLOCK NUT,1/4 NC
20
21986
4
LOCKWASHER,1/4
SWITCH BOX AND JOYSTICK 5101E
