Overview
The N784 Series Media Converter is a standalone physical layer device that converts
between 10/100BaseT(X) and 100BaseFX segments of the same network. The converter
supports Link Fault Pass-through (LFP) for easy tracing of network link failures, and the
LFP function enhances the integrity and conformity of twisted pair (TP)-Fiber linking to
make the network easier to maintain. The converter is powered by an external power
adapter or USB port on the hosting device (e.g., PC).
Package Checklist
• Media Converter
• AC-DC Power Adapter (100-240V)
• Owner’s Manual
Model Description
N784-001-SC 10/100BaseT(X) to 100BaseFX media converter; multi mode,
SC type fiber connection
N784-001-ST 10/100BaseT(X) to 100BaseFX media converter; multi mode,
ST type fiber connection
Panel Layout
• Front Panel View
• Side Panel View
