Transcend Information TS4GSDOM22V User Manual
Page 5
T
T
T
S
S
S
1
1
1
2
2
2
8
8
8
M
M
M
-
-
-
8
8
8
G
G
G
S
S
S
D
D
D
O
O
O
M
M
M
2
2
2
2
2
2
V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.2
5
Pin Assignments
Pin No.
Pin Name
Pin No.
Pin Name
01 GND 02 A+
03 A- 04
GND
05 B- 06 B+
07 GND 08 NC
09 NC 10 NC
11 GND 12 GND
13 GND 14 5V
15 5V 16 5V
17 GND 18 GND
19 GND 20 NC
21 NC 22 NC
Pin Layout
Pin out
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22
GN
D
A+
A-
GN
D
B-
B+
GN
D
NC
NC
NC
GN
D
GN
D
GN
D
5V
5V
5V
GN
D
GN
D
GN
D
NC
NC
NC
This manual is related to the following products:
