Tripp Lite IS1000HG User Manual
Model #: is1000hg

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
Model #: IS1000HG
Isolation Transformer - Medical Grade line noise reduction and spike suppression
Highlights
Complete line isolation, noise filtering and surge suppression; ideal for
sensitive equipment
1000 watts, 4 outlets, 10-ft. power cord
Hospital-grade plug and receptacles
Leakage less than 100 microamps
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases
Description
Isolator Series UL60601-1 Listed Medical Grade Isolation Transformers offer line isolation, continuous noise filtering and enhanced common mode
surge suppression. An internal low-impedance isolation transformer component offers 100% isolation from the input AC line. Full UL60601-1
medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator medical-grade transformers ideal for protection of medical
electronic equipment in patient-care areas. Faraday shield reduces the cumulative leakage current of the Isolator and connected equipment to levels
less than 100 microamps. Secondary neutral-to-ground bonding virtually eliminates common mode noise, providing an isolated neutral-ground
reference for sensitive equipment, and an inexpensive alternative to dedicated circuits and site electrical upgrades. Removes EMI/RFI noise, utility
switching transients and harmonics generated by other on-site loads and utility or lightning related surge conditions. Active transformer filtering
provides continuous common-mode noise rejection with no wearable parts. Unique ability to reduce surges in the worst of power environments to
harmless levels. Reduces 6000V IEEE587 Cat A&B ring wave and combination wave test surges to only 0.5V common mode. Model IS1000HG
includes 4 widely spaced NEMA 5-15R hospital-grade output receptacles, a 10-ft. power cord, hospital-grade input plug, circuit breaker overload
protection, and lighted power switch. Rugged all-metal unit housing; ships ready for placement in any industrial, medical, office or network
environment. PLUG/OUTLETS: Input - NEMA 5-15P Hospital Grade; Output - 4 NEMA 5-15R Hospital Grade ELECTRICAL: 120V AC, 60Hz, 8.3A
(Requires NEMA 5-15R wall receptacle)
Package Includes
IS1000HG Isolation Transformer
Instruction manual with warranty information
Features
The IS1000HG Medical Grade Isolation Transformer offers line isolation and continuous noise filtering
Internal low-impedance isolation transformer with Faraday shield offers 100% isolation from the input AC line
Full UL60601-1 medical-grade listing with hospital-grade plug and outlet receptacles makes Isolator Hospital Grade transformers ideal for
the protection of sensitive electronic equipment in patient-care areas
Reduces the cumulative leakage current of the Isolator and connected equipment to levels less than 100 microamps
Secondary neutral to ground bonding eliminates common mode noise, providing an isolated ground reference for sensitive equipment
Serves as an inexpensive alternative to the installation of dedicated circuits and site electrical upgrades
Removes EMI/RFI noise, utility switching transients, load generated harmonics and ground loops
Active transformer filtering offers continuous common-mode noise rejection with no wearable parts, uniquely able to reduce surges in the
worst of power environments to harmless levels
Reduces 6000V IEEE587 Cat A&B ring wave and combination wave test surges to only 0.5V common mode
Includes 4 widely spaced NEMA5-15R hospital grade output receptacles, a 10-ft power cord, hospital grade input plug, circuit breaker
overload protection and lighted power switch
Rugged all-metal unit housing; ships ready for upright tower placement in any industrial, medical, office or network environment
Specifications
