Item Part No. Qty. Description
40288 Accumulator
2 4022636 Air Filter, Pleated, 2” x 20” x 20”
402264 Air Filter, Pleated, 4” x 20” x 20”
MERV-8
4022624 Air Filter, Pleated, 4” x 20” x 20”
(90-95% EFFICIENT)
3 402083 Blower w/ Capacitor
4 4022622 2 Bumper, Foot, .50 Dia. x .75 High
5 407777 2 Capillary Tubes, .059” ID x .24”
OD x 32” long
6 4022563 Coil, Condenser
7 4022557 Coil, Evaporator
8 4022600 Compressor, Carlyle
(P/N EBA35A)(HP Model)
4023645 Compressor Kit, Carlyle
(P/N EBA20A) (4022750
Compressor only)
9 4022595 Compressor Overload, Carlyle
(included with compressor)
0 4022634 Condensate Pump
402265 Cord and Wire Harness
2 402908 Drain Hose
(.38 ID x .56 OD x 33’ long)
3 40226 Outlet Collar (for Ducting Outlet)
4 4022593 Filter/Drier (not shown)
5 402597 Hour Meter
6 402089 Indicator Light, Red, 25V
7 402266 Instruction Label (not shown)
8 402229 Low Pressure Control
9 97000 Relay
20 4022740 Run Capacitor, 30 MFD, 370V
2 402997 6 Spring
22 402796 Switch, Pump Purge
23 402822 Switch, Power
24 402470 Thermostat, Defrost
402648 Thermostat, Defrost,
Mounting Clip
25 402823 Timer, Defrost
26 4022878 Time Delay (HP Model)
27 402263 2 Wheel, 2”, Plastic
20
15
12
1
13
23
24
25
26
11
4
7
8
17
18
2
19
22
14
16
3
27
10
26
6
9
6 Service Parts
Items listed are not shown
4022597 Wiring Diagram (on Cover)
(not shown)
402950 Ground Fault Interrupter
(optional)
4023079 Coupling, Body,
Quick Connect, .38 Tube
4023080 Coupling, Insert,
Quick Connect,.38 Tube
Specifications subject to change without notice.
