266X CompactFlash Card

Transcend Information Inc.

Of these bits, bits 7 through 2 are reserved. Bit 0, if set to one, indicates that the CompactFlash Storage
Card supports PIO mode 3. Bit 1, if set to one, indicates that the CompactFlash StorageCard supports
PIO mode 4.
Support for PIO modes 5 and above are specific to CompactFlash are reported in word 163.

Word 65: Minimum Multiword DMA transfer cycle time

Word 65 of the parameter information of the Identify Device command is defined as the minimum
Multiword DMA transfer cycle time. This field defines, in nanoseconds, the minimum cycle time that, if
used by the host, the CompactFlash Storage Card guarantees data integrity during the transfer.
If this field is supported, bit 1 of word 53 shall be set to one. The value in word 65 shall not be less than the
minimum cycle time for the fastest DMA mode supported by the device. This field shall be supported by all
CompactFlash Storage Cards supporting DMA modes 1 and above. If bit 1 of word 53 is set to one, but
this field is not supported, the Card shall return a value of zero in this field.

Recommended Multiword DMA transfer cycle time

Word 66 of the parameter information of the Identify Device command is defined as the recommended
Multiword DMA transfer cycle time. This field defines, in nanoseconds, the cycle time that, if used by the
host, may optimize the data transfer from by reducing the probability that the CompactFlash Storage Card
will need to negate the DMARQ signal during the transfer of a sector.
If this field is supported, bit 1 of word 53 shall be set to one. The value in word 66 shall not be less than the
value in word 65. This field shall be supported by all CompactFlash Storage Cards supporting DMA
modes 1 and above. If bit 1 of word 53 is set to one, but this field is not supported, the Card shall return a
value of zero in this field.

Word 67: Minimum PIO transfer cycle time without flow control

Word 67 of the parameter information of the Identify Device command is defined as the minimum PIO
transfer without flow control cycle time. This field defines, in nanoseconds, the minimum cycle time that, if
used by the host, the CompactFlash Storage Card guarantees data integrity during the transfer without
utilization of flow control. If this field is supported, Bit 1 of word 53 shall be set to one. Any CompactFlash
Storage Card that supports PIO mode 3 or above shall support this field, and the value in word 67 shall
not be less than the value reported in word 68. If bit 1 of word 53 is set to one because a CompactFlash
Storage Card supports a field in words 64-70 other than this field and the CompactFlash Storage Card
does not support this field, the CompactFlash Storage Card shall return a value of zero in this field.

Word 68: Minimum PIO transfer cycle time with IORDY

Word 68 of the parameter information of the Identify Device command is defined as the minimum PIO
transfer with IORDY flow control cycle time. This field defines, in nanoseconds, the minimum cycle time
that the CompactFlash Storage Card supports while performing data transfers while utilizing IORDY flow
control. If this field is supported, Bit 1 of word 53 shall be set to one. Any CompactFlash Storage Card that
supports PIO mode 3 or above shall support this field, and the value in word 68 shall be the fastest
defined PIO mode supported by the CompactFlash Storage Card. If bit 1 of word 53 is set to one because
a CompactFlash Storage Card supports a field in words 64-70 other than this field and the CompactFlash
Storage Card does not support this field, the CompactFlash Storage Card shall return a value of zero in
this field.

Words 82-84: Features/command sets supported

Words 82, 83, and 84 shall indicate features/command sets supported. The value 0000h or FFFFh was
placed in each of these words by CompactFlash Storage Cards prior to ATA-3 and shall be interpreted by
the host as meaning that features/command sets supported are not indicated. Bits 1 through 13 of word
83 and bits 0 through 13 of word 84 are reserved. Bit 14 of word 83 and word 84 shall be set to one and bit
15 of word 83 and word 84 shall be cleared to zero to provide indication that the features/command sets
supported words are valid. The values in these words should not be depended on by host implementers.
