Quick Start Guide
Milan M18
Milan M18 Quickstart Guide v1.0 - Page - 2
Technical Specifications
Dimensions (h x w x d) 600mm x 700mm x 600mm (23.6” x 27.6” x 23.6”)
Net weight 45 kg (99lbs)
Components 1 x 18”(457mm) LF driver
Frequency response 36Hz – 80Hz/125Hz ±3dB, 28Hz – 80Hz/125Hz ±10dB
Maximum SPL 125dB continuous, 131dB peak
Construction 18mm plywood enclosure finished in dark blue textured paint
Connectors Input: (2) Jack/XLR female, wired pin 2 hot; Link: (2) XLR male, wired pin 2 hot;
Output: (2) XLR male, wired pin 2 hot; IEC mains connector
Controls Level, switchable high-pass filter at 80Hz or 125Hz, phase invert, ground lift
Indicators Signal / Limit bi-colour LED (signal: green, limit: red), power LED
Amplifier TYPE: Class D
POWER OUTPUT: 1000 watts continuous @ 8 ohms (1kHz, 0.01% THD)
MAX INPUT: +20dBu
USER EQUALISATION: switchable low-pass filter at 80Hz or 125Hz
LIMITING: Thermal limiter, current overload
POWER REQUIREMENTS: 110V AC @ 50Hz or 230V AC @60Hz
Spares and Accessories
LS-1816 18” low frequency loudspeaker
RC-1816 Recone kit
M18AMP Amplifier module
Turbosound Ltd., Star Road, West Sussex RH13 8RY, UK
tel: +44(0)1403 711447 fax: +44(0)1403 710155
www.turbosound.com
version 1.0 05/10
