The First Years Swing Gate - Manual (Page 2)

2
7
1
release handle
2
release buttons (
2)
3
carry handle
4
adjustment buckle tabs
5
adjustment buckles
6
panels
7
top hinge pin
8
adjustment knobs (
4)
9
hinge pin release slider
bk
lower hinge pin
bl
two-sided mounting template
13
10
2 3 4 5
6
9
1
12
11
17 16 15 14
bm 2" wood screws (8)
bn
safety brackets (
2)**
bo
upper hinge bracket
bp
1/8" hinge bracket spacers (
2)*
bq
9/16" hinge bracket spacer*
br
lower hinge bracket
*When using the gate in hardware mode in a
doorway with a baseboard, you might need to
use these hinge bracket spacers.
**IMPORTANT: When installing the gate at the top
of the stairs, you must install the safety brackets.
