8
120 Watt Universal AC/DC Notebook Power Adapter
Specifications
Troubleshooting
The adapter’s status light is not on - what do I do?
First, make sure that the AC wall socket cable or DC Auto/Air
input cable is firmly connected to a power source, such as a
wall outlet, power supply connector or cigarette lighter socket.
If the problem still exists, try the following for your connection
type.
AC wall socket connection
• Check that the wall outlet or power strip has power.
Dimensions
(L x W x H) Power Adapter:
5.6 x 3.1 x 0.66 inches
(14.22 x 13.28 x 3.94 cm)
Weight (overall) 11.4 ounces (323 g)
AC wall socket input cable 4.75 inches (12 cm)
DC Auto/Air input cable 18 inches (0.46 m)
DC power output cable 10 feet (3.05 m)
Input Voltage 100-120/200-240 volts AC
12 to 16 volts DC
Output Voltage 0 to 24 volts DC (configurable)
Output current 6 Amps maximum (configurable)
Output power up to 120 watts (maximum)
