Specifications M2500 M3000 M6000
Standard Specifications for Each Unit
Cabinet 16 and 18 gauge galvanized steel
Finish Pearl white epoxy, baked on, oil resistant
Air Flow Horizontal — right to left or left to right, optional side discharge (M3000 & M6000)
Filter Access Hinged doors — M3000 & M6000. End loading — M2500.
Drain Prefilter & main filter drain (M2500 - no drain)
Plenum Source capture with inlet collar (14" or 20" dia.), with no hole, dual arm (M3000 & M6000 only)
Agency Approvals UL Listed Components
*secondary filter typically used with HEPA and Adsorber Modules
Dimensions 47" L x 25" W x 25" H 68" L x 25" W x 26.25" H 73.5" L x 49" W x 30" H
Installation Suspended, Wall or Frame Mounted
Weight 180 lbs./Shipping 250 lbs. 260 Lbs./Shipping 330 lbs. 610 Lbs./700 lbs.
Electrical: .75HP: 120VAC/60/1ph 2 HP: 208-240/480/60/3ph 7.5 HP: 208-240/480/60/3ph
Standard 10.5 Amps 5.8/2.9 Amps 19.8/9.9 Amps
Optional N/A 2 HP: 575/60/3ph 5HP: 208-230/460/60/3ph
3 HP: 208-240/480/60/3ph-9.1/4.6 Amps 13.4/6.7 Amps
3 HP: 575/60/3ph 5 HP: 575/60/3ph
7.5 HP: 575/60/3ph
Motors: Thermally protected TEFC, Ball Bearings TEFC, Ball bearings
Standard 1740 RPM (standard); 3450 RPM (optional) 1740 RPM (standard); 3450 RPM (optional)
Blowers: Direct drive, forward curved Belt drive, forward curved Belt drive, forward curved
Standard
Optional N/A Belt drive, backward inclined, N/A
airfoil, 3HP high static
Air Volume 1240-2010 1300-3300 (factory set 3000) 3500-7100 (factory set 6000)
(CFM) Throw distance: 70 ft. Throw distance: 80 ft.
Controls 3-speed selector switch Motor starter (optional) Motor starter (optional)
Sound Rating 50-70 dB @ 5 ft. 74 dB @ 5 ft. 80 dB @ 5 ft.
Filters:
Pre
4 inch 35% pleated (standard) 4 inch 35% pleated (standard) 2 ea. 4 inch 35% pleated (standard)
Polyester pad (optional) 2 inch aluminum mesh (optional) 2 ea. 2 inch aluminum mesh (optional)
3-way wrap around (optional) 2 inch impinger (optional) 2 ea. 2 inch impinger (optional)
3 way wrap around (optional)
Primary 95% Bag filter (standard) 95% bag filter (standard) 2 ea. 95% bag filter (standard)
65% Bag filter (optional) 65-95% extended surface (optional) 2 ea. 65-95% extended surface (optional)
99.97% HEPA (optional)* 2 ea.99.97% HEPA (optional)*
2 ea. Adsorber Modules (optional)* 4 ea. Adsorber Modules (optional)*
(25 lbs. carbon each) (25 lbs. carbon each)
Secondary N/A 95% short bag (optional)* 2 ea. 95% short bag (optional)*
Gauge Kit (Optional) Manometer or Magnehelic to indicate when filters need changing
Silencer (Optional) NA Reduces sound to 72.5 dB. Reduces sound to 78 dB.
