PARTS INFORMATION
Page 18
TED-262L/DH
HANDLES & THROTTLE • FIGURE 12
ITEM
PART NUMBER
DESCRIPTION
QTY
COMMENTS
12-28
2583217081
HANDLE,A
1
12-29
05532130200
GRIP,HANDLE
1
12-30
10132120201
LEVER,THROTTLE
1
12-34
99011050221
SCREW,5X22
1
~N204150
12-34
99051050253
BOLT,HEX,5X25
1
N204151~
12-35
99101050011
NUT,5
2
~N204150
12-35
99178050010
NUT,LOCK 5
1
N204151~
12-36
19833130200
CLAMP,CORD
1
12-37
99023060161
BOLT,6X16 PLUS
1
12-38
99210060012
WASHER,S,6
1
12-39
25932120810
HANDLE,B
1
12-42
99210100012
WASHER,S,10
1
12-45-2 1703217680
SWITCH,STOP
1
~Z248301
12-45-1 16201300900
SWITCH,STOP
1
From N204150 to Z248300
12-45
1703218480
SWITCH,STOP
1
N204151~
12-46
64033210202
METAL,HOLDING
1
~N204150
12-47
26833210210
COVER
1
~N204150
12-48
99414040161
SCREW,S,4X16
1
~N204150
12-49
99101040011
NUT,4
1
~N204150
12-50
11533210202
BRACKET
2
12-52-1 1780162S800
CORD,STOP
1
~N204150
12-53
1641003200
TUBE,PROTECTION,10X320
1
12-54
1641003201
TUBE,PROTECTION,10X321
1
12-55
0473217581
HANDLE
1
N157001~
12-56
99201060011
WASHER,6
2
12-57
99210060012
WASHER,S,6
2
12-58
99023060121
BOLT,PLUS,6X12
2
12-59
99201100011
WASHER,10
2
12-60
99210100012
WASHER,S,10
2
12-61
99021100201
BOLT,10X20
2
12-65
1013217590
LEVER,THROTTLE ASS'Y
1
12-70
6403246521
BRACKET,STOP BUTTON
1
Z248301~
12-70-1 2723218420
BRACKET
1
From N204151 to Z248300
12-70
11532170200
BRACKET
1
~N204150
12-71
2581165020
BUTTON,STOP
1
N204151~
12-72
99011030101
SCREW,3X10
1
N204151~
12-76
9253317620
DECAL,STOP BUTTON
1
N204151~
12-81
8850162S800
WIRE,THROTTLE
1
12-82
1780162T80
CORD,STOP
1
~N157000
12-82
1790162T80
CORD,STOP
1
N157001~
12-83
8850163N80
WIRE,THROTTLE
1
Z248301~
12-83
8850162T81
WIRE,THROTTLE
1
From N204151 to Z248300
12-83
8850162U80
WIRE,THROTTLE
1
~N204150
12-84
64033210202
METAL,HOLDING
1
12-85
26833210210
COVER
1
12-86
1703217680
SWITCH,STOP
1
Z248301~
12-86
1703217580
SWITCH,STOP
1
~Z248300
12-87
99101040011
NUT,4
1
12-88
99414040161
SCREW,S,4X16
1
12-90
19833130200
CLAMP,CORD
1
