19
Hints for test centres
Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse
aid dispenser.
IST23en
Test standard EN 50242
Reference programme: Power Wash 65°C with prewash
Load: 8 standard place settings
Rinse aid selector: position 4
Detergent dosage : 20 g in the dispenser
5 g on the dispenser lid
US56
UI57
Arrangement
upper basket Arrangement
lower basket
DIMENSIONS Width 45 cm
Height with worktop 85 cm
Height without worktop 82 cm
Max depth 60 cm
Max depth with open door 115.9 cm
ELECTRICAL CONNECTION Voltage 220/240 V - 50 Hz
MOTOR RATING DURING WASH 200 W
POWER OF HEATING ELEMENT 2570 W
OVERALL POWER 2770 W
WATER SUPPLY PRESSURE Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
CAPACITY 8 place settings
Technical specifications
