background image

53

Specification

Mechanism:

high precision linear tracking drive

GaAlAs semiconductor laser: 785 nm / 10 mW

(VCD / CD)

650 nm / 7 mW

(DVD / SACD)

Formats

Video

DVD, DVD+R / +RW, DVD-R / -RW, VCD, SVCD

Audio

CD, CD-R / RW, MP3-CD, SACD Stereo + Multi channel


Picture CD (JPEG)

Audio section

Analogue audio outputs

2 x Stereo, 6 x Multi channel, 2 x Stereo TV

Digital audio outputs

1 x coaxial, 1 optical,

IEC 60958 (CDDA / LPCM),
IEC 61937 (MPEG1/2, Dolby Digital, dts)

D / A converter for CD, DVD, (S)VCD, MP3

front channels (MCH analog OUT)

Stereo channels L/R

Surround channels / Center / Subwoofer

Downmix (TV)

Double-Mono Differential 2x24 Bit / 384 kHz Sigma / Delta converter

4 x 24 Bit / 384 kHz Sigma / Delta

2 x 24 Bit / 384 kHz Sigma / Delta

D / A converter for SACD

front channels

surround channels

Double-Mono DSD differential converter

DSD-differential converter

Frequency response:

CD

SACD normal

SACD wide

DVD-V

DVD 96/24

2 Hz

20 kHz

2 Hz

60 kHz

2 Hz

– 120 kHz

2 Hz

-

22 kHz

2 Hz

-

44 kHz

Total harmonic distortion / Intermodulation:

< 0.001 %

Effective system dynamics CD / SACD:

100 dB / 110 dB

Signal / noise ratio:

115 dB

Channel separation:

110 dB

Video section

TV-Standard:
lines:

625 (PAL, 50 Hz) / 525 (NTSC, 60 Hz)

Progressive Scan

576 P, 480 P (Component)

Video-Format:

MPEG 1 für VCD / MPEG 2 für DVD

DVD:
resolution horizontal / vertical:

720 Pixel / 576 lines (50 Hz) / 480 lines (60 Hz)

VCD:
resolution horizontal / vertical:

352 Pixel / 288 lines (50 Hz) / 240 lines (60 Hz)

Video DA Converter

12-bit / 216 MHz

Bandwidth

12.5 MHz (Luma), 6 MHz (Chroma)

Video-Output:

1.0 V

SS

/ 75 Ω

S-Video Output:

(Y)

1.0 V

SS

/ 75 Ω

(C)

300 mV

SS

(Burst) / 75 Ω

RGB (SCART-Output):

0.7 V

SS

/ 75 Ω

Analogue-Audio-Output:

1.9 V

eff

/ 450 Ω

General

Power supply:

230 V / 50 Hz, 40 VA oder / or 117 V / 60 Hz, 40 VA
(see print on back panel)

standard accessories:

power cable, R

LINK

-cable, Video-cable, Stereo cable

User manual

We reserve the right to introduce technically founded modifications.
